Description
Width, mm
11,7
Height, mm
9,4
Length, mm
13,2
Weight, g
3.1
The color
is colorless
Body material
UL94V-2 thermoplastic plastic
Contact material
phosphorous bronze
Contact coverage
1.27 microns of gold on a nickel substrate with a thickness of 2.50 microns
Operating temperature range
– 40 ° C to + 60 ° C
Additional information
| Brand | Molex |
|---|---|
| Vendor Part Number | 02-558P |
