Layer 3 Managed Network Switch, 24x GbE RJ45, 4x SFP+, stackable, optional redundant PSU
252,00 ₾
Layer 3 Managed Network Switch, 24x GbE RJ45, 4x SFP+, stackable, optional redundant PSU
- აღწერა
- დამატებითი ინფორმაცია
- More Products
- Store Policies
- Enquiries
აღწერა
Network Protocol
IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w,
IEEE 802.1d, IEEE 802.1s, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3AB, IEEE 802.1p, IEEE 802.1D, IEEE 802.1x
Gigabit Ethernet Ports
24
10Gigabit SFP+ ports
4
The maximum number of supported modules
SM-10G: 4
MM-10G: 4
RJ45-10G: 2
Console
1
Channel aggregation
14
External backup power supply
12V/5 A (60W)
Additional ports
1 vent hole
Redirection mode
Accumulation and transfer
Total bandwidth without blocking
64 Gbps
Switching speed
128 Gbps
The redirection rate
is 95.232 Mbit/s
Packet Buffer
12 MB
Network delay
<4µs
Switching
• 16 thousand static or dynamic MAC address records with filtering
• 4 thousand VLANs, port-based VLANs, IEEE 802.1Q VLAN tags, Voice VLAN
• Virtual VLAN interface
• GVRP (under development)
• Spanning tree, 32 instances for STP/RSTP/MSTP
Routing
• Static routing
• Dynamic routing, including RIP, RIPng, OSPF and OSPFv3
• Routing according to the policy (in development)
Multicast broadcast
• IGMP Snooping
• MLD Snooping
• MVR (in development)
QoS/ACL
• Port prioritization
• Prioritization scheme
• Priority schedule, including SP, WRR, WFQ, SP-WRR and SP-WFQ
• Traffic management
• Speed limit
• 2 thousand. ACLs for Ethernet, IPv4 and IPv6
DHCP
DHCP Server, DHCP Relay, DHCP Option 82, 60, 160 and 43
Service
CPU and Memory Monitoring, SNMP, RMON, LLDP and LLDP-MED, Backup and Recovery, System Log, Diagnostics
including Ping, Traceroute, Port Mirroring, UDLD (TBD) and Copper Test
Safety
• User hierarchy management and password protection, HTTPS, SSH, Telnet
• 802.1X authentication
• AAA authentication, including RADIUS, TACACS+
• Storm Control
• Port Isolation, Port Protection, Sticky MAC
• MAC address filtering
• IP Source Guard, protection against DoS attacks, ARP Inspection
• DHCP Snooping
• Loop protection, including BPDU protection, root protection (in development) and loop detection (in development)
• Kensington socket (for Kensington locks)
დამატებითი ინფორმაცია
| წონა | 3 კგ |
|---|---|
| Brand | Grandstream |
| Model | GWN7813 |
| Vendor Part Number | GWN7813 |
-
